PCP1402-TD-H Datasheet
Datasheet specifications
| Datasheet's name | PCP1402 |
|---|---|
| File size | 504.983 KB |
| File type | |
| Number of pages | 5 |
Download Datasheet PCP1402 |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: ON Semiconductor
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- FET Type: N-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 250V
- Current - Continuous Drain (Id) @ 25°C: 1.2A (Ta)
- Drive Voltage (Max Rds On, Min Rds On): 10V
- Rds On (Max) @ Id, Vgs: 2.4Ohm @ 600mA, 10V
- Vgs(th) (Max) @ Id: 3.5V @ 1mA
- Gate Charge (Qg) (Max) @ Vgs: 4.2nC @ 10V
- Vgs (Max): ±30V
- Input Capacitance (Ciss) (Max) @ Vds: 210pF @ 20V
- FET Feature: -
- Power Dissipation (Max): 3.5W (Tc)
- Operating Temperature: 150°C (TJ)
- Mounting Type: Surface Mount
- Supplier Device Package: SOT-89/PCP-2
- Package / Case: TO-243AA
- Base Part Number: PCP1402
- detail: N-Channel 250V 1.2A (Ta) 3.5W (Tc) Surface Mount SOT-89/PCP-2
