MBRD1035CTLT4G دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | MBRD1035CTLT4G |
|---|---|
| حجم فایل | 75.94 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 6 |
دانلود دیتاشیت MBRD1035CTLT4G |
دانلود دیتاشیت |
|---|
سایر مستندات
MBRD1035CTL, SBRD81035CTL Series 6 pages
مشخصات فنی
- RoHS: true
- Category: Diodes/Schottky Barrier Diodes (SBD)
- Datasheet: onsemi MBRD1035CTLT4G
- Diode Configuration: Dual Common Cathode
- Reverse Voltage (Vr): 35V
- Forward Voltage (Vf@If): 470mV@5A
- Reverse Leakage Current (Ir): 2mA@35V
- Average Rectified Current (Io): 5A
- Package: TO-252
- Manufacturer: onsemi
- Series: SWITCHMODE™
- Packaging: Cut Tape (CT)
- Part Status: Obsolete
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 35V
- Current - Average Rectified (Io) (per Diode): 5A
- Voltage - Forward (Vf) (Max) @ If: 470mV @ 5A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Current - Reverse Leakage @ Vr: 2mA @ 35V
- Operating Temperature - Junction: -55°C ~ 150°C
- Mounting Type: Surface Mount
- Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- Supplier Device Package: DPAK
- Base Part Number: MBRD1035
- detail: Diode Array 1 Pair Common Cathode Schottky 35V 5A Surface Mount TO-252-3, DPak (2 Leads + Tab), SC-63
