FDMA6023PZT دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت FDMA6023PZT	دانلود دیتاشیت

مستندات دیگری یافت نشد!

RoHS: true
Type: 2 P-Channel
Category: Triode/MOS Tube/Transistor/MOSFETs
Operating Temperature: -55°C~+150°C@(Tj)
Power Dissipation (Pd): 700mW
Total Gate Charge (Qg@Vgs): 17nC@4.5V
Input Capacitance (Ciss@Vds): 885pF@10V
Continuous Drain Current (Id): 3.6A
Gate Threshold Voltage (Vgs(th)@Id): 1.5V@250uA
Drain Source On Resistance (RDS(on)@Vgs,Id): 60mΩ@3.6A,4.5V
Package: UMLP-6
Manufacturer: onsemi
Series: PowerTrench®
Packaging: Cut Tape (CT)
Part Status: Active
FET Type: 2 P-Channel (Dual)
FET Feature: Logic Level Gate
Drain to Source Voltage (Vdss): 20V
Current - Continuous Drain (Id) @ 25°C: 3.6A
Rds On (Max) @ Id, Vgs: 60mOhm @ 3.6A, 4.5V
Vgs(th) (Max) @ Id: 1.5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs: 17nC @ 4.5V
Input Capacitance (Ciss) (Max) @ Vds: 885pF @ 10V
Power - Max: 700mW
Mounting Type: Surface Mount
Package / Case: 6-UDFN Exposed Pad
Supplier Device Package: 6-MicroFET (2x2)
Base Part Number: FDMA60
detail: Mosfet Array 2 P-Channel (Dual) 20V 3.6A 700mW Surface Mount 6-MicroFET (2x2)
