MC74AC74, MC74ACT74 دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | MC74AC74, MC74ACT74 |
|---|---|
| حجم فایل | 99.431 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 10 |
دانلود دیتاشیت MC74AC74, MC74ACT74 |
دانلود دیتاشیت |
|---|
سایر مستندات
MC74AC74DR2G 10 pages
مشخصات فنی
- RoHS: true
- Type: D-Type
- Series: 74ACT
- Category: Logic ICs/Flip Flops
- Function: 置位和复位
- Datasheet: onsemi MC74ACT74DR2G
- Output Type: 互补型
- Sink Current: 24mA
- Trigger Type: 上升沿
- Source Current: 24mA
- Supply Voltage: 4.5V~5.5V
- Clock Frequency: 210MHz
- Input Capacitance: 4.5pF
- Number of Elements: 2
- Operating Temperature: -40°C~+85°C
- Quiescent Current (Iq): 4uA
- Maximum Propagation Delay: 11ns@5V,50pF
- Number of Bits per Element: 1
- Package: SOP-14
- Manufacturer: onsemi
- Packaging: Tube
- Part Status: Obsolete
- Max Propagation Delay @ V, Max CL: 11ns @ 5V, 50pF
- Current - Output High, Low: 24mA, 24mA
- Voltage - Supply: 4.5V ~ 5.5V
- Current - Quiescent (Iq): 4µA
- Mounting Type: Surface Mount
- Supplier Device Package: 14-SOIC
- Package / Case: 14-SOIC (0.154", 3.90mm Width)
- Base Part Number: MC74ACT74
- detail: Flip Flop 2 Element D-Type 1 Bit Positive Edge 14-SOIC (0.154", 3.90mm Width)
