دیتاشیت MC78M18CDTRKG
مشخصات دیتاشیت
| نام دیتاشیت | MC78M00(A), NCV78M00 Series |
|---|---|
| حجم فایل | 141.284 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 15 |
دانلود دیتاشیت MC78M00(A), NCV78M00 Series |
MC78M00(A), NCV78M00 Series Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: onsemi MC78M18CDTRKG
- Output Current: 500mA
- Output Voltage: 18V
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 35V
- Operating Temperature: 0°C~+125°C
- Power Supply Rejection Ratio (PSRR): 70dB@(120Hz)
- Package: DPAK-3
- Manufacturer: onsemi
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Obsolete
- Output Configuration: Positive
- Output Type: Fixed
- Number of Regulators: 1
- Voltage - Input (Max): 35V
- Voltage - Output (Min/Fixed): 18V
- Voltage - Output (Max): -
- Voltage Dropout (Max): -
- Current - Output: 500mA
- PSRR: 70dB (120Hz)
- Control Features: -
- Protection Features: Over Temperature, Short Circuit
- Mounting Type: Surface Mount
- Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- Supplier Device Package: DPAK
- Base Part Number: MC78M18
- detail: Linear Voltage Regulator IC 1 Output 500mA DPAK
