NCV8170AXV330T2G دیتاشیت

NCV8170AXV330T2G

مشخصات دیتاشیت

نام دیتاشیت NCV8170AXV330T2G
حجم فایل 71.719 کیلوبایت
نوع فایل pdf
تعداد صفحات 23

دانلود دیتاشیت NCV8170AXV330T2G

دانلود دیتاشیت

سایر مستندات

NCV8170 21 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: onsemi NCV8170AXV330T2G
  • Output Current: 150mA
  • Output Voltage: 3.3V
  • Dropout Voltage: 0.25V@(150mA)
  • Output Polarity: positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 5.5V
  • Operating Temperature: -40°C~+125°C
  • Quiescent Current (Ground Current): 0.9uA
  • Power Supply Rejection Ratio (PSRR): 41dB@(1kHz)
  • Package: SOT-563
  • Manufacturer: onsemi
  • Series: Automotive, AEC-Q100
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Output Configuration: Positive
  • Output Type: Fixed
  • Number of Regulators: 1
  • Voltage - Input (Max): 5.5V
  • Voltage - Output (Min/Fixed): 3.3V
  • Voltage - Output (Max): -
  • Voltage Dropout (Max): 0.25V @ 150mA
  • Current - Output: 150mA
  • Current - Quiescent (Iq): 0.9µA
  • PSRR: 41dB (1kHz)
  • Control Features: Enable
  • Protection Features: Over Current, Over Temperature
  • Mounting Type: Surface Mount
  • Package / Case: SOT-563, SOT-666
  • Supplier Device Package: SOT-563-6
  • Base Part Number: NCV8170
  • detail: Linear Voltage Regulator IC 1 Output 150mA SOT-563-6
