NSVJ3910SB3T1G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NSVJ3910SB3T1G
|
|
حجم فایل
|
54.234
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
5
|
مشخصات فنی
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/JFETs
-
FET Type:
N-Channel
-
Datasheet:
onsemi NSVJ3910SB3T1G
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Input Capacitance (Ciss@Vds):
6pF@5V
-
Total Device Dissipation (Pd):
400mW
-
Drain Current (Idss@Vds,Vgs=0):
20mA@5V
-
Gate-Source Breakdown Voltage (V(BR)GSS):
25V
-
Gate-Source Cutoff Voltage (VGS(off)@ID):
600mV@100uA
-
Package:
CPH-3
-
Manufacturer:
onsemi
-
Series:
Automotive, AEC-Q101
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Voltage - Breakdown (V(BR)GSS):
25V
-
Drain to Source Voltage (Vdss):
25V
-
Current - Drain (Idss) @ Vds (Vgs=0):
20mA @ 5V
-
Current Drain (Id) - Max:
50mA
-
Voltage - Cutoff (VGS off) @ Id:
600mV @ 100µA
-
Input Capacitance (Ciss) (Max) @ Vds:
6pF @ 5V
-
Power - Max:
400mW
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-236-3, SC-59, SOT-23-3
-
Supplier Device Package:
3-CPH
-
Base Part Number:
NSVJ39
-
detail:
JFET N-Channel 25V 50mA 400mW Surface Mount 3-CPH
