74LCX32MX دیتاشیت

74LCX32MX

مشخصات دیتاشیت

نام دیتاشیت 74LCX32MX
حجم فایل 68.843 کیلوبایت
نوع فایل pdf
تعداد صفحات 14

مشاهده دیتاشیت 74LCX32MX

دانلود دیتاشیت

سایر مستندات

مستندات دیگری یافت نشد!

مشخصات فنی

  • RoHS: true
  • Series: 74LCX
  • Category: Logic ICs/Gates
  • Datasheet: onsemi 74LCX32MX
  • Sink Current: 24mA
  • Source Current: 24mA
  • Supply Voltage: 2V~3.6V
  • Logic Gate Type: ORGate
  • Number of Channels: 4
  • Low Level Range (VIL): 0.7V~0.8V
  • Operating Temperature: -40°C~+85°C
  • High Level Range (VIH): 1.7V~2V
  • Propagation Delay Time: 5.5ns@3.3V,50pF
  • Quiescent Current (Max): 10uA
  • Package: SOP-14
  • Manufacturer: onsemi
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Logic Type: OR Gate
  • Number of Circuits: 4
  • Number of Inputs: 2
  • Features: -
  • Voltage - Supply: 2V ~ 3.6V
  • Current - Quiescent (Max): 10µA
  • Current - Output High, Low: 24mA, 24mA
  • Logic Level - Low: 0.7V ~ 0.8V
  • Logic Level - High: 1.7V ~ 2V
  • Max Propagation Delay @ V, Max CL: 5.5ns @ 3.3V, 50pF
  • Mounting Type: Surface Mount
  • Supplier Device Package: 14-SOIC
  • Package / Case: 14-SOIC (0.154", 3.90mm Width)
  • Base Part Number: 74LCX32
  • detail: OR Gate IC 4 Channel 14-SOIC
