FDMC8032L دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت FDMC8032L	دانلود دیتاشیت

مستندات دیگری یافت نشد!

RoHS: true
Type: 2 N-Channel
Category: Triode/MOS Tube/Transistor/MOSFETs
Datasheet: onsemi FDMC8032L
Operating Temperature: -55°C~+150°C@(Tj)
Power Dissipation (Pd): 1.9W
Total Gate Charge (Qg@Vgs): 11nC@10V
Drain Source Voltage (Vdss): 40V
Input Capacitance (Ciss@Vds): 720pF@20V
Continuous Drain Current (Id): 7A
Gate Threshold Voltage (Vgs(th)@Id): 3V@250uA
Drain Source On Resistance (RDS(on)@Vgs,Id): 20mΩ@7A,10V
Package: Power-33-8
Manufacturer: onsemi
Series: PowerTrench®
Packaging: Cut Tape (CT)
Part Status: Active
FET Type: 2 N-Channel (Dual)
FET Feature: Logic Level Gate
Drain to Source Voltage (Vdss): 40V
Current - Continuous Drain (Id) @ 25°C: 7A
Rds On (Max) @ Id, Vgs: 20mOhm @ 7A, 10V
Vgs(th) (Max) @ Id: 3V @ 250µA
Gate Charge (Qg) (Max) @ Vgs: 11nC @ 10V
Input Capacitance (Ciss) (Max) @ Vds: 720pF @ 20V
Power - Max: 1.9W
Mounting Type: Surface Mount
Package / Case: 8-PowerWDFN
Supplier Device Package: 8-Power33 (3x3)
Base Part Number: FDMC80
detail: Mosfet Array 2 N-Channel (Dual) 40V 7A 1.9W Surface Mount 8-Power33 (3x3)
