- دیتاشیت MC74ACT574DWR2G
MC74ACT574DWR2G دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | MC74ACT574DWR2G |
|---|---|
| حجم فایل | 75.317 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 10 |
دانلود دیتاشیت MC74ACT574DWR2G |
دانلود دیتاشیت |
|---|
سایر مستندات
MC74AC574, MC74ACT574 10 pages
مشخصات فنی
- RoHS: true
- Type: D-Type
- Series: 74ACT
- Category: Logic ICs/Flip Flops
- Function: -
- Datasheet: onsemi MC74ACT574DWR2G
- Output Type: Tri-State;Non-Inverted
- Sink Current: 24mA
- Trigger Type: 上升沿
- Source Current: 24mA
- Supply Voltage: 4.5V~5.5V
- Clock Frequency: 100MHz
- Input Capacitance: 4.5pF
- Quiescent Current (Iq): 8uA
- Maximum Propagation Delay: 11ns@5V,50pF
- Package: SOP-20-300mil
- Manufacturer: onsemi
- Packaging: Tube
- Part Status: Obsolete
- Number of Elements: 1
- Number of Bits per Element: 8
- Max Propagation Delay @ V, Max CL: 11ns @ 5V, 50pF
- Current - Output High, Low: 24mA, 24mA
- Voltage - Supply: 4.5V ~ 5.5V
- Current - Quiescent (Iq): 8µA
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Supplier Device Package: 20-SOIC
- Package / Case: 20-SOIC (0.295", 7.50mm Width)
- Base Part Number: MC74ACT574
- detail: Flip Flop 1 Element D-Type 8 Bit Positive Edge 20-SOIC (0.295", 7.50mm Width)
