دیتاشیت FDMA1023PZ
مشخصات دیتاشیت
| نام دیتاشیت |
FDMA1023PZ
|
| حجم فایل |
401.59
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
7
|
مشخصات
-
Manufacturer:
ON Semiconductor
-
Series:
PowerTrench®
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
FET Type:
2 P-Channel (Dual)
-
FET Feature:
Logic Level Gate
-
Drain to Source Voltage (Vdss):
20V
-
Current - Continuous Drain (Id) @ 25°C:
3.7A
-
Rds On (Max) @ Id, Vgs:
72mOhm @ 3.7A, 4.5V
-
Vgs(th) (Max) @ Id:
1.5V @ 250µA
-
Gate Charge (Qg) (Max) @ Vgs:
12nC @ 4.5V
-
Input Capacitance (Ciss) (Max) @ Vds:
655pF @ 10V
-
Power - Max:
700mW
-
Operating Temperature:
-55°C ~ 150°C (TJ)
-
Mounting Type:
Surface Mount
-
Package / Case:
6-VDFN Exposed Pad
-
Supplier Device Package:
6-MicroFET (2x2)
-
Base Part Number:
FDMA10
-
detail:
Mosfet Array 2 P-Channel (Dual) 20V 3.7A 700mW Surface Mount 6-MicroFET (2x2)
