NUP4004M5T1G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NUP4004M5T1G
|
|
حجم فایل
|
84.398
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
4
|
مشخصات فنی
-
RoHS:
true
-
Category:
TVS/Fuse/Board Level Protection/ESD Protection Devices
-
Polarity:
Bi-Directional
-
Datasheet:
onsemi NUP4004M5T1G
-
Clamping Voltage@Ipp:
-
-
Operating Temperature:
-40°C~+125°C@(Tj)
-
Breakdown Voltage (VBR):
7V
-
Peak Pulse Power(Ppp)@8/20us:
-
-
Junction Capacitance(Cj)@1MHz:
-
-
Reverse Stand-Off Voltage (Vrwm):
5V
-
Package:
TSOP-5-1.5mm
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Type:
Zener
-
Bidirectional Channels:
4
-
Voltage - Reverse Standoff (Typ):
5V (Max)
-
Voltage - Breakdown (Min):
-
-
Voltage - Clamping (Max) @ Ipp:
-
-
Current - Peak Pulse (10/1000µs):
-
-
Power - Peak Pulse:
-
-
Power Line Protection:
No
-
Applications:
General Purpose
-
Capacitance @ Frequency:
-
-
Mounting Type:
Surface Mount
-
Package / Case:
SOT-23-5 Thin, TSOT-23-5
-
Supplier Device Package:
5-TSOP
-
Base Part Number:
NUP4004
-
detail:
Clamp Ipp Tvs Diode Surface Mount 5-TSOP
