HSMW-C191 数据手册

HSMW-C191, HSMW-130/265/197/120

数据手册规格

数据手册名称 HSMW-C191, HSMW-130/265/197/120
文件大小 162.42 千字节
文件类型 pdf
页数 11

下载数据手册 HSMW-C191, HSMW-130/265/197/120

下载数据手册

其他文档

未找到其他文档！

技术规格

  • Manufacturer: Broadcom Limited
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Color: White
  • Configuration: Standard
  • Lens Color: White
  • Lens Transparency: Diffused
  • Millicandela Rating: 200mcd
  • Lens Style: Rectangle with Flat Top
  • Lens Size: 1.00mm x 1.60mm
  • Voltage - Forward (Vf) (Typ): 3.6V
  • Current - Test: 20mA
  • Viewing Angle: 140°
  • Mounting Type: Surface Mount
  • Wavelength - Dominant: -
  • Wavelength - Peak: -
  • Features: -
  • Package / Case: 0603 (1608 Metric)
  • Supplier Device Package: Chip LED
  • Size / Dimension: 1.60mm L x 0.80mm W
  • Height (Max): 0.60mm
  • Base Part Number: HSMW-C191
  • detail: White LED Indication - Discrete 3.6V 0603 (1608 Metric)
