دیتاشیت NTMFS5C430NLT1G
مشخصات دیتاشیت
| نام دیتاشیت |
NTMFS5C430NL
|
| حجم فایل |
132.188
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
6
|
مشخصات
-
RoHS:
true
-
Type:
N Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
onsemi NTMFS5C430NLT1G
-
Power Dissipation (Pd):
3.8W
-
Drain Source Voltage (Vdss):
40V
-
Continuous Drain Current (Id):
-
-
Gate Threshold Voltage (Vgs(th)@Id):
2V@250uA
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
1.5mΩ@10V,50A
-
Package:
DFN-5(5.9x4.9)
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
FET Type:
N-Channel
-
Technology:
MOSFET (Metal Oxide)
-
Drain to Source Voltage (Vdss):
40V
-
Current - Continuous Drain (Id) @ 25°C:
-
-
Drive Voltage (Max Rds On, Min Rds On):
4.5V, 10V
-
Rds On (Max) @ Id, Vgs:
1.5mOhm @ 50A, 10V
-
Vgs(th) (Max) @ Id:
2V @ 250µA
-
Gate Charge (Qg) (Max) @ Vgs:
70nC @ 10V
-
Vgs (Max):
±20V
-
Input Capacitance (Ciss) (Max) @ Vds:
4300pF @ 20V
-
FET Feature:
-
-
Power Dissipation (Max):
3.8W (Ta), 110W (Tc)
-
Operating Temperature:
-55°C ~ 175°C (TJ)
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
5-DFN (5x6) (8-SOFL)
-
Package / Case:
8-PowerTDFN
-
Base Part Number:
NTMFS5
-
detail:
N-Channel 40V 3.8W (Ta), 110W (Tc) Surface Mount 5-DFN (5x6) (8-SOFL)
