SRV05-4MR6T1G دیتاشیت

SRV05-4MR6T1G

مشخصات دیتاشیت

نام دیتاشیت SRV05-4MR6T1G
حجم فایل 90.97 کیلوبایت
نوع فایل pdf
تعداد صفحات 10

دانلود دیتاشیت SRV05-4MR6T1G

دانلود دیتاشیت

سایر مستندات

SRV05-4MR6 9 pages

SRV05-4MR6T1G 4 pages

مشخصات فنی

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
  • Datasheet: onsemi SRV05-4MR6T1G
  • Number of Lines: 4
  • Clamping Voltage@Ipp: 17.5V
  • Operating Temperature: -55°C~+125°C@(Tj)
  • Breakdown Voltage (VBR): 6V
  • Peak Pulse Power(Ppp)@8/20us: 300W
  • Junction Capacitance(Cj)@1MHz: 3pF@1MHz
  • Reverse Stand-Off Voltage (Vrwm): 5V
  • Package: SOT-23-6
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Type: Steering (Rail to Rail)
  • Unidirectional Channels: 4
  • Voltage - Reverse Standoff (Typ): 5V (Max)
  • Voltage - Breakdown (Min): 6V
  • Voltage - Clamping (Max) @ Ipp: 17.5V
  • Current - Peak Pulse (10/1000µs): 5A (8/20µs)
  • Power - Peak Pulse: 300W
  • Power Line Protection: Yes
  • Applications: General Purpose
  • Capacitance @ Frequency: 3pF @ 1MHz
  • Mounting Type: Surface Mount
  • Package / Case: SOT-23-6 Thin, TSOT-23-6
  • Supplier Device Package: 6-TSOP
  • Base Part Number: SRV05
  • detail: 17.5V Clamp 5A (8/20µs) Ipp Tvs Diode Surface Mount 6-TSOP
