ASMB-LTC2-0A335 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
ASMB-LTC2-0A335
|
|
حجم فایل
|
1281.329
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
13
|
مشخصات فنی
-
Manufacturer:
Broadcom Limited
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Color:
Red, Green, Blue (RGB)
-
Configuration:
Common Anode
-
Lens Color:
-
-
Lens Transparency:
Diffused
-
Millicandela Rating:
70mcd Red, 300mcd Green, 50mcd Blue
-
Lens Style:
Round with Flat Top
-
Lens Size:
1.60mm Dia
-
Voltage - Forward (Vf) (Typ):
2V Red, 2.7V Green, 2.7V Blue
-
Current - Test:
5mA Red, 5mA Green, 5mA Blue
-
Viewing Angle:
105°
-
Mounting Type:
Surface Mount
-
Wavelength - Dominant:
621nm Red, 525nm Green, 468nm Blue
-
Wavelength - Peak:
630nm Red, 516nm Green, 465nm Blue
-
Features:
-
-
Package / Case:
4-SMD, J-Lead
-
Supplier Device Package:
4-PLCC
-
Size / Dimension:
2.10mm L x 2.10mm W
-
Height (Max):
1.20mm
-
detail:
Red, Green, Blue (RGB) 621nm Red, 525nm Green, 468nm Blue LED Indication - Discrete 2V Red, 2.7V Green, 2.7V Blue 4-SMD, J-Lead
