SMDA05CDR2G دیتاشیت

SMDA05CDR2G

مشخصات دیتاشیت

نام دیتاشیت SMDA05CDR2G
حجم فایل 71.657 کیلوبایت
نوع فایل pdf
تعداد صفحات 6

مشاهده دیتاشیت SMDA05CDR2G

دانلود دیتاشیت

سایر مستندات

SMDA05C Series 6 pages

مشخصات فنی

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
  • Datasheet: onsemi SMDA05CDR2G
  • Number of Lines: 4
  • Clamping Voltage@Ipp: 11V
  • Operating Temperature: -55°C~+150°C@(Tj)
  • Breakdown Voltage (VBR): 6V
  • Peak Pulse Power(Ppp)@8/20us: 300W
  • Junction Capacitance(Cj)@1MHz: 350pF@1MHz
  • Reverse Stand-Off Voltage (Vrwm): 5V
  • Package: SOP-8
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Type: Zener
  • Bidirectional Channels: 4
  • Voltage - Reverse Standoff (Typ): 5V (Max)
  • Voltage - Breakdown (Min): 6V
  • Voltage - Clamping (Max) @ Ipp: 11V
  • Current - Peak Pulse (10/1000µs): 17A (8/20µs)
  • Power - Peak Pulse: 300W
  • Power Line Protection: No
  • Applications: General Purpose
  • Capacitance @ Frequency: 350pF @ 1MHz
  • Mounting Type: Surface Mount
  • Package / Case: 8-SOIC (0.154", 3.90mm Width)
  • Supplier Device Package: 8-SOIC
  • Base Part Number: SMDA
  • detail: 11V Clamp 17A (8/20µs) Ipp Tvs Diode Surface Mount 8-SOIC
