MUR1510(15,20,40,60) 数据手册
数据手册规格
| 数据手册名称 | MUR1510(15,20,40,60) |
|---|---|
| 文件大小 | 138.583 千字节 |
| 文件类型 | |
| 页数 | 8 |
下载数据手册 MUR1510(15,20,40,60) |
下载数据手册 |
|---|
其他文档
MUR1560G 8 pages
技术规格
- RoHS: true
- Category: Diodes/Diodes - Fast Recovery Rectifiers
- Datasheet: onsemi MUR1540G
- Diode Configuration: Single
- Reverse Voltage (Vr): 400V
- Operating Temperature: -65°C~+175°C@(Tj)
- Forward Voltage (Vf@If): 1.25V@15A
- Reverse Leakage Current: 10uA@400V
- Reverse Recovery Time (trr): 60ns
- Average Rectified Current (Io): 15A
- Package: TO-220-2
- Manufacturer: onsemi
- Series: SWITCHMODE™
- Packaging: Tube
- Part Status: Obsolete
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 400V
- Current - Average Rectified (Io): 15A
- Voltage - Forward (Vf) (Max) @ If: 1.25V @ 15A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Current - Reverse Leakage @ Vr: 10µA @ 400V
- Capacitance @ Vr, F: -
- Mounting Type: Through Hole
- Package / Case: TO-220-2
- Supplier Device Package: TO-220-2
- Operating Temperature - Junction: -65°C ~ 175°C
- Base Part Number: MUR15
- detail: Diode Standard 400V 15A Through Hole TO-220-2
