MBR2045EMFST1G دیتاشیت

MBR2045EMFST1G

مشخصات دیتاشیت

نام دیتاشیت MBR2045EMFST1G
حجم فایل 74.378 کیلوبایت
نوع فایل pdf
تعداد صفحات 6

مشاهده دیتاشیت MBR2045EMFST1G

دانلود دیتاشیت

سایر مستندات

MBR2045EMFS, NRVB2045EMFS 5 pages

مشخصات فنی

  • RoHS: true
  • Category: Diodes/Schottky Barrier Diodes (SBD)
  • Datasheet: onsemi MBR2045EMFST1G
  • Diode Configuration: Single
  • Reverse Voltage (Vr): 45V
  • Forward Voltage (Vf@If): 510mV@20A
  • Reverse Leakage Current (Ir): 90uA@45V
  • Average Rectified Current (Io): 20A
  • Package: SO-8FL
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Diode Type: Schottky
  • Voltage - DC Reverse (Vr) (Max): 45V
  • Current - Average Rectified (Io): 20A
  • Voltage - Forward (Vf) (Max) @ If: 640mV @ 20A
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Current - Reverse Leakage @ Vr: 400µA @ 45V
  • Capacitance @ Vr, F: -
  • Mounting Type: Surface Mount
  • Package / Case: 8-PowerTDFN, 5 Leads
  • Supplier Device Package: 5-DFN (5x6) (8-SOFL)
  • Operating Temperature - Junction: -55°C ~ 150°C
  • Base Part Number: MBR2045
  • detail: Diode Schottky 45V 20A Surface Mount 5-DFN (5x6) (8-SOFL)
