دیتاشیت LM337D2TR4G
مشخصات دیتاشیت
| نام دیتاشیت |
LM337D2TR4G
|
| حجم فایل |
84.023
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
11
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
onsemi LM337D2TR4G
-
Package:
TO-263
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Obsolete
-
Output Configuration:
Negative
-
Output Type:
Adjustable
-
Number of Regulators:
1
-
Voltage - Input (Max):
-40V
-
Voltage - Output (Min/Fixed):
-1.2V
-
Voltage - Output (Max):
-37V
-
Voltage Dropout (Max):
-
-
Current - Output:
1.5A
-
Current - Quiescent (Iq):
6mA
-
Current - Supply (Max):
10mA
-
PSRR:
77dB (120Hz)
-
Control Features:
-
-
Protection Features:
Over Current, Over Temperature
-
Operating Temperature:
0°C ~ 125°C
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
-
Supplier Device Package:
D2PAK
-
Base Part Number:
LM337
-
detail:
Linear Voltage Regulator IC 1 Output 1.5A D2PAK
