DF10M Datasheet

DF10M

Datasheet specifications

Datasheet's name DF10M
File size 98.62 KB
File type pdf
Number of pages 2

Download Datasheet DF10M

Download Datasheet

Other documentations

DF005M - DF10M 7 pages

DF04M 3 pages

Technical specifications

  • RoHS: true
  • Category: Diodes/Bridge Rectifiers
  • Datasheet: Diodes Incorporated DF10M
  • Reverse Voltage (Vr): 1kV
  • Operating Temperature: -65°C~+150°C@(Tj)
  • Forward Voltage (Vf@If): 1.1V@1A
  • Peak Forward Surge Current: 50A
  • Reverse Leakage Current (Ir): 10uA@1kV
  • Average Rectified Current (Io): 1A
  • Package: DFM
  • Manufacturer: Diodes Incorporated
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Diode Type: Single Phase
  • Technology: Standard
  • Voltage - Peak Reverse (Max): 1kV
  • Current - Average Rectified (Io): 1.5A
  • Voltage - Forward (Vf) (Max) @ If: 1.1V @ 1A
  • Current - Reverse Leakage @ Vr: 5µA @ 1000V
  • Mounting Type: Through Hole
  • Package / Case: 4-EDIP (0.300", 7.62mm)
  • Supplier Device Package: 4-DIP
  • Base Part Number: DF10
  • detail: Bridge Rectifier Single Phase Standard 1kV Through Hole 4-DIP
