دیتاشیت 6N136M

6N135M-36M, HCPL4503M HCPL2530M-31M

مشخصات دیتاشیت

نام دیتاشیت 6N135M-36M, HCPL4503M HCPL2530M-31M
حجم فایل 680.14 کیلوبایت
نوع فایل pdf
تعداد صفحات 20

دانلود دیتاشیت 6N135M-36M, HCPL4503M HCPL2530M-31M

6N135M-36M, HCPL4503M HCPL2530M-31M Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Number of Channels: 1
  • Voltage - Isolation: 5000Vrms
  • Current Transfer Ratio (Min): 19% @ 16mA
  • Current Transfer Ratio (Max): 50% @ 16mA
  • Turn On / Turn Off Time (Typ): 250ns, 260ns
  • Rise / Fall Time (Typ): -
  • Input Type: DC
  • Output Type: Transistor with Base
  • Voltage - Output (Max): 20V
  • Current - Output / Channel: 8mA
  • Voltage - Forward (Vf) (Typ): 1.45V
  • Current - DC Forward (If) (Max): 25mA
  • Vce Saturation (Max): -
  • Operating Temperature: -40°C ~ 100°C
  • Mounting Type: Through Hole
  • Package / Case: 8-DIP (0.300", 7.62mm)
  • Supplier Device Package: 8-DIP
  • Base Part Number: 6N136
  • detail: Optoisolator Transistor with Base Output 5000Vrms 1 Channel 8-DIP
