دیتاشیت H11L2M
مشخصات دیتاشیت
| نام دیتاشیت |
H11L1M-3M
|
| حجم فایل |
340.884
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
9
|
مشخصات
-
RoHS:
true
-
Category:
Optocoupler/LED/Digital Tube/Photoelectric Device/Optocouplers - Logic Output
-
Datasheet:
onsemi H11L2M
-
Input Type:
DC
-
Supply Voltage:
3V~15V
-
Number of Channels:
1
-
Operating Temperature:
-40°C~+85°C
-
Isolation Voltage(rms):
4170V
-
Propagation Delay tpLH/tpHL:
4us
-
Common Mode Transient Immunity (CMTI):
-
-
Package:
DIP-6
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Active
-
Inputs - Side 1/Side 2:
1/0
-
Voltage - Isolation:
4170Vrms
-
Common Mode Transient Immunity (Min):
-
-
Output Type:
Open Collector
-
Current - Output / Channel:
50mA
-
Data Rate:
1MHz
-
Propagation Delay tpLH / tpHL (Max):
4µs, 4µs
-
Rise / Fall Time (Typ):
100ns, 100ns
-
Voltage - Forward (Vf) (Typ):
1.2V
-
Current - DC Forward (If) (Max):
30mA
-
Voltage - Supply:
3V ~ 15V
-
Mounting Type:
Through Hole
-
Package / Case:
6-DIP (0.300", 7.62mm)
-
Supplier Device Package:
6-DIP
-
Base Part Number:
H11L
-
detail:
Logic Output Optoisolator 1MHz Open Collector 4170Vrms 1 Channel CMTI 6-DIP
