FAN73912MX دیتاشیت

FAN73912MX

مشخصات دیتاشیت

نام دیتاشیت FAN73912MX
حجم فایل 78.653 کیلوبایت
نوع فایل pdf
تعداد صفحات 20

مشاهده دیتاشیت FAN73912MX

دانلود دیتاشیت

سایر مستندات

FAN73912 22 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Gate Drive ICs
  • Datasheet: onsemi FAN73912MX
  • Fall Time: 15ns
  • Load Type: IGBT;MOSFET
  • Rise Time: 25ns
  • Supply Voltage: 12V~20V
  • Number of Drivers: 2
  • Driven Configuration: Half Bridge
  • Operating Temperature: -40°C~+125°C@(Tj)
  • Peak Output Current(sink): 3A
  • Peak Output Current(source): 2A
  • Package: SOP-16-300mil
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Channel Type: Independent
  • Gate Type: IGBT, N-Channel, P-Channel MOSFET
  • Voltage - Supply: 12V ~ 20V
  • Logic Voltage - VIL, VIH: 6V, 9.5V
  • Current - Peak Output (Source, Sink): 2A, 3A
  • Input Type: -
  • High Side Voltage - Max (Bootstrap): 1200V
  • Rise / Fall Time (Typ): 25ns, 15ns
  • Mounting Type: Surface Mount
  • Package / Case: 16-SOIC (0.295", 7.50mm Width)
  • Supplier Device Package: 16-SOIC
  • Base Part Number: FAN7391
  • detail: Half-Bridge Gate Driver IC 16-SOIC
