دیتاشیت MBR40250TG

MBR(F)40250(T)

مشخصات دیتاشیت

نام دیتاشیت MBR(F)40250(T)
حجم فایل 83.187 کیلوبایت
نوع فایل pdf
تعداد صفحات 7

دانلود دیتاشیت MBR(F)40250(T)

MBR(F)40250(T) Datasheet

مشخصات

  • RoHS: true
  • Category: Diodes/Schottky Barrier Diodes (SBD)
  • Datasheet: onsemi MBR40250TG
  • Reverse Voltage (Vr): 250V
  • Forward Voltage (Vf@If): 970mV@40A
  • Reverse Leakage Current (Ir): 30uA@250V
  • Average Rectified Current (Io): 40A
  • Package: TO-220
  • Manufacturer: onsemi
  • Series: SWITCHMODE™
  • Packaging: Tube
  • Part Status: Obsolete
  • Diode Type: Schottky
  • Voltage - DC Reverse (Vr) (Max): 250V
  • Current - Average Rectified (Io): 40A
  • Voltage - Forward (Vf) (Max) @ If: 970mV @ 40A
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Reverse Recovery Time (trr): 35ns
  • Current - Reverse Leakage @ Vr: 30µA @ 250V
  • Capacitance @ Vr, F: 500pF @ 5V, 1MHz
  • Mounting Type: Through Hole
  • Package / Case: TO-220-3
  • Supplier Device Package: TO-220AB
  • Operating Temperature - Junction: -65°C ~ 150°C
  • Base Part Number: MBR40250
  • detail: Diode Schottky 250V 40A Through Hole TO-220AB
