NCV7608DQR2G دیتاشیت

NCV7608

مشخصات دیتاشیت

نام دیتاشیت NCV7608
حجم فایل 257.993 کیلوبایت
نوع فایل pdf
تعداد صفحات 27

مشاهده دیتاشیت NCV7608

دانلود دیتاشیت

سایر مستندات

مستندات دیگری یافت نشد!

مشخصات فنی

  • Manufacturer: ON Semiconductor
  • Series: Automotive, AEC-Q100
  • Packaging: Cut Tape (CT)
  • Part Status: Discontinued at Digi-Key
  • Output Configuration: Half Bridge (4)
  • Applications: DC Motors, Lamps, Relays
  • Interface: SPI
  • Load Type: Inductive, Capacitive, Resistive
  • Technology: Power MOSFET
  • Rds On (Typ): 1.2Ohm
  • Current - Output / Channel: -
  • Current - Peak Output: 250mA
  • Voltage - Supply: 3.15V ~ 5.25V
  • Voltage - Load: 5.5V ~ 28V
  • Operating Temperature: -40°C ~ 150°C (TJ)
  • Features: Slew Rate Controlled, Status Flag
  • Fault Protection: Current Limiting, Open Load Detect, Over Temperature, Over Voltage, UVLO
  • Mounting Type: Surface Mount
  • Package / Case: 36-BFSOP (0.295", 7.50mm Width) Exposed Pad
  • Supplier Device Package: 36-SSOP
  • Base Part Number: NCV7608
  • detail: Half Bridge (4) Driver DC Motors, Lamps, Relays Power MOSFET 36-SSOP
