دیتاشیت ACPL-M43U-000E

ACPL-M43U-000E

مشخصات دیتاشیت

نام دیتاشیت ACPL-M43U-000E
حجم فایل 246.069 کیلوبایت
نوع فایل pdf
تعداد صفحات 8

دانلود دیتاشیت ACPL-M43U-000E

ACPL-M43U-000E Datasheet

مشخصات

  • Manufacturer: Broadcom Limited
  • Series: R²Coupler™
  • Packaging: Tube
  • Part Status: Active
  • Number of Channels: 1
  • Voltage - Isolation: 3750Vrms
  • Current Transfer Ratio (Min): 32% @ 10mA
  • Current Transfer Ratio (Max): 80% @ 10mA
  • Turn On / Turn Off Time (Typ): 200ns, 300ns
  • Rise / Fall Time (Typ): -
  • Input Type: DC
  • Output Type: Transistor
  • Voltage - Output (Max): 20V
  • Current - Output / Channel: 8mA
  • Voltage - Forward (Vf) (Typ): 1.5V
  • Current - DC Forward (If) (Max): 20mA
  • Vce Saturation (Max): -
  • Operating Temperature: -40°C ~ 125°C
  • Mounting Type: Surface Mount
  • Package / Case: 6-SOIC (0.173", 4.40mm Width), 5 Leads
  • Supplier Device Package: 5-SO
  • detail: Optoisolator Transistor Output 3750Vrms 1 Channel 5-SO
