دیتاشیت HDSP-7801
مشخصات دیتاشیت
| نام دیتاشیت | HDSP-7x0x,A15x,A40x |
|---|---|
| حجم فایل | 214.167 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 10 |
دانلود دیتاشیت HDSP-7x0x,A15x,A40x |
HDSP-7x0x,A15x,A40x Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Nixie Tube Driver/LED Driver/Led Segment Display
- Datasheet: Broadcom/AVAGO HDSP-7801
- Module Size: 12.7mmx7.62mmx6.09mm
- Display Type: 7段
- LED Polarity: Common anode
- Luminous Color: Green
- Power Dissipation: 105mW
- Number of Characters: 1Bit
- Digit/Alpha Size(inch): 0.3
- Package: Plugin
- Manufacturer: Broadcom/AVAGO
- Series: -
- Packaging: Tube
- Part Status: Active
- Size / Dimension: 0.500" H x 0.300" W x 0.240" D (12.70mm x 7.62mm x 6.09mm)
- Digit/Alpha Size: 0.30" (7.62mm)
- Common Pin: Common Anode
- Color: Green
- Voltage - Forward (Vf) (Typ): 2.1V
- Current - Test: 10mA
- Millicandela Rating: 6.8mcd
- Wavelength - Peak: 566nm
- Power Dissipation (Max): 105mW
- Package / Case: 10-DIP (0.200", 5.08mm)
- detail: Display Modules - LED Character and Numeric Green 7-Segment 1 Character Common Anode 2.1V 10mA 0.500" H x 0.300" W x 0.240" D (12.70mm x 7.62mm x 6.09mm) 10-DIP (0.200", 5.08mm)
