دیتاشیت HCPL-0701-500E
مشخصات دیتاشیت
| نام دیتاشیت |
HCPL-0701-500E
|
| حجم فایل |
165.919
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
14
|
مشخصات
-
RoHS:
true
-
Category:
Optocoupler/LED/Digital Tube/Photoelectric Device/Optocouplers - Phototransistor Output
-
Datasheet:
Broadcom/AVAGO HCPL-0701-500E
-
Output Current:
60mA
-
Forward Voltage:
1.4V
-
Number of Outputs:
1
-
Operating Temperature:
-40°C~+85°C
-
Isolation Voltage(rms):
3750V
-
Package:
SO-8
-
Manufacturer:
Broadcom/AVAGO
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Active
-
Number of Channels:
1
-
Voltage - Isolation:
3750Vrms
-
Current Transfer Ratio (Min):
500% @ 1.6mA
-
Current Transfer Ratio (Max):
2600% @ 1.6mA
-
Turn On / Turn Off Time (Typ):
200ns, 2µs
-
Rise / Fall Time (Typ):
-
-
Input Type:
DC
-
Output Type:
Darlington with Base
-
Voltage - Output (Max):
18V
-
Current - Output / Channel:
60mA
-
Voltage - Forward (Vf) (Typ):
1.4V
-
Current - DC Forward (If) (Max):
20mA
-
Vce Saturation (Max):
-
-
Mounting Type:
Surface Mount
-
Package / Case:
8-SOIC (0.154", 3.90mm Width)
-
Supplier Device Package:
8-SO
-
detail:
Optoisolator Darlington with Base Output 3750Vrms 1 Channel 8-SO
