- ACPL-847-00GE
ACPL-847-00GE Datasheet
Datasheet specifications
| Datasheet's name | ACPL-847-00GE |
|---|---|
| File size | 70.58 KB |
| File type | |
| Number of pages | 12 |
Download Datasheet ACPL-847-00GE |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- RoHS: true
- Category: Optocoupler/LED/Digital Tube/Photoelectric Device/Optocouplers - Phototransistor Output
- Datasheet: Broadcom Limited ACPL-847-00GE
- Fall time: 3us
- Rise time: 4us
- Output Current: 50mA
- Forward Voltage: 1.2V
- Number of Outputs: 4
- Operating Temperature: -30°C~+100°C
- Isolation Voltage(rms): 5000V
- Package: DIP-16
- Manufacturer: Broadcom Limited
- Series: -
- Packaging: Tube
- Part Status: Active
- Number of Channels: 4
- Voltage - Isolation: 5000Vrms
- Current Transfer Ratio (Min): 130% @ 5mA
- Current Transfer Ratio (Max): 400% @ 5mA
- Turn On / Turn Off Time (Typ): -
- Rise / Fall Time (Typ): 4µs, 3µs
- Input Type: DC
- Output Type: Transistor
- Voltage - Output (Max): 70V
- Current - Output / Channel: 50mA
- Voltage - Forward (Vf) (Typ): 1.2V
- Current - DC Forward (If) (Max): 50mA
- Vce Saturation (Max): 200mV
- Mounting Type: Through Hole
- Package / Case: 16-DIP (0.300", 7.62mm)
- Supplier Device Package: 16-DIP
- detail: Optoisolator Transistor Output 5000Vrms 4 Channel 16-DIP
