دیتاشیت FCH067N65S3-F155

FCH067N65S3

مشخصات دیتاشیت

نام دیتاشیت FCH067N65S3
حجم فایل 463.155 کیلوبایت
نوع فایل pdf
تعداد صفحات 10

دانلود دیتاشیت FCH067N65S3

FCH067N65S3 Datasheet

مشخصات

  • RoHS: true
  • Category: Triode/MOS Tube/Transistor/MOSFETs
  • Datasheet: onsemi FCH067N65S3-F155
  • Operating Temperature: -55°C~+150°C@(Tj)
  • Power Dissipation (Pd): 312W
  • Total Gate Charge (Qg@Vgs): 78nC@10V
  • Drain Source Voltage (Vdss): 650V
  • Input Capacitance (Ciss@Vds): 3090pF@400V
  • Continuous Drain Current (Id): 44A
  • Gate Threshold Voltage (Vgs(th)@Id): 4.5V@4.4mA
  • Reverse Transfer Capacitance (Crss@Vds): -
  • Drain Source On Resistance (RDS(on)@Vgs,Id): 67mΩ@22A,10V
  • Package: TO-247
  • Manufacturer: onsemi
  • Series: SuperFET® III
  • Packaging: Tube
  • Part Status: Active
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 650V
  • Current - Continuous Drain (Id) @ 25°C: 44A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Rds On (Max) @ Id, Vgs: 67mOhm @ 22A, 10V
  • Vgs(th) (Max) @ Id: 4.5V @ 4.4mA
  • Gate Charge (Qg) (Max) @ Vgs: 78nC @ 10V
  • Vgs (Max): ±30V
  • Input Capacitance (Ciss) (Max) @ Vds: 3090pF @ 400V
  • FET Feature: Super Junction
  • Power Dissipation (Max): 312W (Tc)
  • Mounting Type: Through Hole
  • Supplier Device Package: TO-247 Long Leads
  • Package / Case: TO-247-3
  • Base Part Number: FCH06
  • detail: N-Channel 650V 44A (Tc) 312W (Tc) Through Hole TO-247 Long Leads
