دیتاشیت FDH45N50F-F133

FDH45N50F_F133

مشخصات دیتاشیت

نام دیتاشیت FDH45N50F_F133
حجم فایل 452.744 کیلوبایت
نوع فایل pdf
تعداد صفحات 10

دانلود دیتاشیت FDH45N50F_F133

FDH45N50F_F133 Datasheet

مشخصات

  • RoHS: true
  • Category: Triode/MOS Tube/Transistor/MOSFETs
  • Datasheet: onsemi FDH45N50F-F133
  • Package: TO-247
  • Manufacturer: onsemi
  • Series: UniFET™
  • Packaging: Tube
  • Part Status: Active
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 500V
  • Current - Continuous Drain (Id) @ 25°C: 45A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Rds On (Max) @ Id, Vgs: 120mOhm @ 22.5A, 10V
  • Vgs(th) (Max) @ Id: 5V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs: 137nC @ 10V
  • Vgs (Max): ±30V
  • Input Capacitance (Ciss) (Max) @ Vds: 6630pF @ 25V
  • FET Feature: -
  • Power Dissipation (Max): 625W (Tc)
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Mounting Type: Through Hole
  • Supplier Device Package: TO-247-3
  • Package / Case: TO-247-3
  • Base Part Number: FDH45
  • detail: N-Channel 500V 45A (Tc) 625W (Tc) Through Hole TO-247-3
