HSMQ-C280 数据手册
其他文档
未找到其他文档！
技术规格
- Manufacturer: Broadcom Limited
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Color: Green
- Configuration: Standard
- Lens Color: White
- Lens Transparency: Diffused
- Millicandela Rating: 223mcd
- Lens Style: Rectangle with Flat Top
- Lens Size: 1.00mm x 0.50mm
- Voltage - Forward (Vf) (Typ): 3.3V
- Current - Test: 20mA
- Viewing Angle: 130°
- Mounting Type: Surface Mount
- Wavelength - Dominant: 522nm
- Wavelength - Peak: 516nm
- Features: -
- Package / Case: 0402 (1005 Metric)
- Supplier Device Package: SMD
- Size / Dimension: 1.00mm L x 0.50mm W
- Height (Max): 0.50mm
- detail: Green 522nm LED Indication - Discrete 3.3V 0402 (1005 Metric)
