HSMF-C144 Datasheet
Datasheet specifications
| Datasheet's name | HSMF-C144 |
|---|---|
| File size | 193.108 KB |
| File type | |
| Number of pages | 7 |
Download Datasheet HSMF-C144 |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: Broadcom Limited
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Color: Green, Red
- Configuration: Common Anode
- Lens Color: Colorless
- Lens Transparency: Clear
- Millicandela Rating: 33mcd Green, 79mcd Red
- Lens Style: Rectangle with Domed Top
- Lens Size: 2.00mm x 1.00mm
- Voltage - Forward (Vf) (Typ): 2V Green, 2V Red
- Current - Test: 20mA Green, 20mA Red
- Viewing Angle: 120°
- Mounting Type: Surface Mount, Right Angle
- Wavelength - Dominant: 570nm Green, 632nm Red
- Wavelength - Peak: 571nm Green, 644nm Red
- Features: -
- Package / Case: 4-SMD
- Supplier Device Package: SMD
- Size / Dimension: 3.00mm L x 2.00mm W
- Height (Max): 1.10mm
- detail: Green, Red 570nm Green, 632nm Red LED Indication - Discrete 2V Green, 2V Red 4-SMD
