HSMM-C120 Datasheet
Datasheet specifications
| Datasheet's name | HSMx-C120 |
|---|---|
| File size | 210.739 KB |
| File type | |
| Number of pages | 10 |
Download Datasheet HSMx-C120 |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: Broadcom Limited
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Color: Green
- Configuration: Standard
- Lens Color: Colorless
- Lens Transparency: Clear
- Millicandela Rating: 120mcd
- Lens Style: Rectangle with Domed Top
- Lens Size: 1.20mm x 0.60mm
- Voltage - Forward (Vf) (Typ): 3.4V
- Current - Test: 20mA
- Viewing Angle: 155°
- Mounting Type: Surface Mount, Right Angle
- Wavelength - Dominant: 525nm
- Wavelength - Peak: 523nm
- Features: -
- Package / Case: 2-SMD, No Lead
- Supplier Device Package: Chip LED
- Size / Dimension: 1.60mm L x 1.00mm W
- Height (Max): 0.60mm
- Base Part Number: HSMM-C120
- detail: Green 525nm LED Indication - Discrete 3.4V 2-SMD, No Lead
