HSMF-C145 Datasheet

HSMF-C145

Datasheet specifications

Datasheet's name HSMF-C145
File size 200.745 KB
File type pdf
Number of pages 8

Download Datasheet HSMF-C145

Download Datasheet

Other documentations

No other documentation was found!

Technical specifications

  • Manufacturer: Broadcom Limited
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Color: Green, Red
  • Configuration: Common Anode
  • Lens Color: Colorless
  • Lens Transparency: Clear
  • Millicandela Rating: 223mcd Green, 79mcd Red
  • Lens Style: Rectangle with Domed Top
  • Lens Size: 2.00mm x 1.00mm
  • Voltage - Forward (Vf) (Typ): 3.4V Green, 2V Red
  • Current - Test: 20mA Green, 20mA Red
  • Viewing Angle: 120°
  • Mounting Type: Surface Mount, Right Angle
  • Wavelength - Dominant: 523nm Green, 632nm Red
  • Wavelength - Peak: 517nm Green, 644nm Red
  • Features: -
  • Package / Case: 4-SMD
  • Supplier Device Package: SMD
  • Size / Dimension: 3.00mm L x 2.00mm W
  • Height (Max): 1.10mm
  • detail: Green, Red 523nm Green, 632nm Red LED Indication - Discrete 3.4V Green, 2V Red 4-SMD
