HCPL-1930 Datasheet

HCPL-1930

Datasheet specifications

Datasheet's name HCPL-1930
File size 237.351 KB
File type pdf
Number of pages 12

Download Datasheet HCPL-1930

Download Datasheet

Other documentations

No other documentation was found!

Technical specifications

  • Manufacturer: Broadcom Limited
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Number of Channels: 2
  • Inputs - Side 1/Side 2: 2/0
  • Voltage - Isolation: 1500VDC
  • Common Mode Transient Immunity (Min): 1kV/µs
  • Input Type: DC
  • Output Type: Open Collector, Schottky Clamped
  • Current - Output / Channel: 25mA
  • Data Rate: 10Mbps
  • Propagation Delay tpLH / tpHL (Max): 100ns, 100ns
  • Rise / Fall Time (Typ): 30ns, 24ns
  • Voltage - Forward (Vf) (Typ): -
  • Current - DC Forward (If) (Max): 60mA
  • Voltage - Supply: 4.5V ~ 5.5V
  • Operating Temperature: -55°C ~ 125°C
  • Mounting Type: Through Hole
  • Package / Case: 16-DIP (0.300", 7.62mm)
  • Supplier Device Package: 16-DIP
  • detail: Logic Output Optoisolator 10Mbps Open Collector, Schottky Clamped 1500VDC 2 Channel 1kV/µs CMTI 16-DIP
