MGM12P Datasheet Datasheet
Datasheet specifications
| Datasheet's name | MGM12P Datasheet |
|---|---|
| File size | 4245.367 KB |
| File type | |
| Number of pages | 100 |
Download Datasheet MGM12P Datasheet |
Download Datasheet |
|---|
Other documentations
MGM12P Errata 19 pages
Technical specifications
- Sensitivity: -105dBm
- Current - Receiving: 10.3mA
- Antenna Type: Antenna Not Included, U.FL
- Package / Case: Module
- RF Family/Standard: 802.15.4, Bluetooth
- Current - Transmitting: 10mA
- Operating Temperature: -40°C ~ 85°C
- Power - Output: 10dBm
- Memory Size: 1MB Flash, 256kB RAM
- Manufacturer: Silicon Labs
- Mounting Type: Surface Mount
- Serial Interfaces: I²C, SPI, UART
- Data Rate: 2Mbps
- Voltage - Supply: 1.8V ~ 3.8V
- Utilized IC / Part: EFR32MG12
- Modulation: 2-FSK, 4-FSK, DSSS, GFSK, GMSK, O-QPSK
- Series: Mighty Gecko
- Packaging: Strip
- Frequency: 2.4GHz
- Part Status: Discontinued at Digi-Key
- detail: 802.15.4, Bluetooth Transceiver Module 2.4GHz Antenna Not Included, U.FL Surface Mount
