HLMP-D101 数据手册
其他文档
HLMP-D101,05, HLMP-K101,05 8 pages
技术规格
- Manufacturer: Broadcom Limited
- Series: -
- Packaging: Bulk
- Part Status: Active
- Color: Red
- Configuration: Standard
- Lens Color: Red
- Lens Transparency: Diffused
- Millicandela Rating: 70mcd
- Lens Style: Round with Domed Top
- Lens Size: 5mm, T-1 3/4
- Voltage - Forward (Vf) (Typ): 1.8V
- Current - Test: 20mA
- Viewing Angle: 65°
- Mounting Type: Through Hole
- Wavelength - Dominant: 637nm
- Wavelength - Peak: 645nm
- Features: -
- Package / Case: Radial
- Supplier Device Package: T-1 3/4
- Size / Dimension: -
- Height (Max): 9.19mm
- Base Part Number: HLMP-D101
- detail: Red 637nm LED Indication - Discrete 1.8V Radial
