دیتاشیت 4N35-W60E

4N35 Series

مشخصات دیتاشیت

نام دیتاشیت 4N35 Series
حجم فایل 221.195 کیلوبایت
نوع فایل pdf
تعداد صفحات 7

دانلود دیتاشیت 4N35 Series

4N35 Series Datasheet

مشخصات

  • Manufacturer: Broadcom Limited
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Number of Channels: 1
  • Voltage - Isolation: 3550Vrms
  • Current Transfer Ratio (Min): 100% @ 10mA
  • Current Transfer Ratio (Max): -
  • Turn On / Turn Off Time (Typ): -
  • Rise / Fall Time (Typ): 3µs, 3µs
  • Input Type: DC
  • Output Type: Transistor with Base
  • Voltage - Output (Max): 30V
  • Current - Output / Channel: 100mA
  • Voltage - Forward (Vf) (Typ): 1.2V
  • Current - DC Forward (If) (Max): 60mA
  • Vce Saturation (Max): 300mV
  • Operating Temperature: -55°C ~ 100°C
  • Mounting Type: Through Hole
  • Package / Case: 6-DIP (0.400", 10.16mm)
  • Supplier Device Package: 6-DIP
  • Base Part Number: 4N35
  • detail: Optoisolator Transistor with Base Output 3550Vrms 1 Channel 6-DIP
