MMBZ27VAWT1G دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | MMBZ27VAWT1G |
|---|---|
| حجم فایل | 88.539 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 5 |
دانلود دیتاشیت MMBZ27VAWT1G |
دانلود دیتاشیت |
|---|
سایر مستندات
مشخصات فنی
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
- Datasheet: onsemi MMBZ27VAWT1G
- Clamping Voltage@Ipp: 40V
- Operating Temperature: -55°C~+150°C@(Tj)
- Breakdown Voltage (VBR): 25.65V
- Peak Pulse Power(Ppp)@8/20us: 40W
- Junction Capacitance(Cj)@1MHz: -
- Reverse Stand-Off Voltage (Vrwm): 22V
- Package: SC-70-3
- Manufacturer: onsemi
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Type: Zener
- Unidirectional Channels: 2
- Bidirectional Channels: 1
- Voltage - Reverse Standoff (Typ): 22V
- Voltage - Breakdown (Min): 25.65V
- Voltage - Clamping (Max) @ Ipp: 40V
- Current - Peak Pulse (10/1000µs): 1A
- Power - Peak Pulse: 40W
- Power Line Protection: No
- Applications: General Purpose
- Capacitance @ Frequency: -
- Mounting Type: Surface Mount
- Package / Case: SC-70, SOT-323
- Supplier Device Package: SC-70-3 (SOT323)
- Base Part Number: MMBZ27
- detail: 40V Clamp 1A Ipp Tvs Diode Surface Mount SC-70-3 (SOT323)
