دیتاشیت HDSP-303G
مشخصات دیتاشیت
نام دیتاشیت |
HDSP-303G
|
حجم فایل |
181.216
کیلوبایت
|
نوع فایل |
pdf
|
تعداد صفحات |
9
|
مشخصات
-
Manufacturer:
Broadcom Limited
-
Series:
-
-
Packaging:
Bulk
-
Part Status:
Active
-
Number of Characters:
1
-
Size / Dimension:
0.504" H x 0.382" W x 0.276" D (12.80mm x 9.70mm x 7.00mm)
-
Digit/Alpha Size:
0.40" (10.16mm)
-
Display Type:
7-Segment
-
Common Pin:
Common Cathode
-
Color:
Green
-
Voltage - Forward (Vf) (Typ):
2.25V
-
Current - Test:
20mA
-
Millicandela Rating:
2.8mcd
-
Wavelength - Peak:
568nm
-
Power Dissipation (Max):
105mW
-
Package / Case:
10-DIP (0.300", 7.62mm)
-
detail:
Display Modules - LED Character and Numeric Green 7-Segment 1 Character Common Cathode 2.25V 20mA 0.504" H x 0.382" W x 0.276" D (12.80mm x 9.70mm x 7.00mm) 10-DIP (0.300", 7.62mm)
