دیتاشیت HCPL-M453-000E

HCPL-M453-000E

مشخصات دیتاشیت

نام دیتاشیت HCPL-M453-000E
حجم فایل 156.107 کیلوبایت
نوع فایل pdf
تعداد صفحات 9

دانلود دیتاشیت HCPL-M453-000E

HCPL-M453-000E Datasheet

مشخصات

  • Manufacturer: Broadcom Limited
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Number of Channels: 1
  • Voltage - Isolation: 3750Vrms
  • Current Transfer Ratio (Min): 20% @ 16mA
  • Current Transfer Ratio (Max): 50% @ 16mA
  • Turn On / Turn Off Time (Typ): 200ns, 600ns
  • Rise / Fall Time (Typ): -
  • Input Type: DC
  • Output Type: Transistor
  • Voltage - Output (Max): 20V
  • Current - Output / Channel: 8mA
  • Voltage - Forward (Vf) (Typ): 1.5V
  • Current - DC Forward (If) (Max): 25mA
  • Vce Saturation (Max): -
  • Operating Temperature: -55°C ~ 100°C
  • Mounting Type: Surface Mount
  • Package / Case: 6-SOIC (0.173", 4.40mm Width), 5 Leads
  • detail: Optoisolator Transistor Output 3750Vrms 1 Channel
