دیتاشیت HDSP-A111

مشخصات دیتاشیت

دانلود دیتاشیت HDSP-Ax1x,Fx1x,Gx1x,Hx1x,Kx1x	HDSP-Ax1x,Fx1x,Gx1x,Hx1x,Kx1x Datasheet

Manufacturer: Broadcom Limited
Series: -
Packaging: Bulk
Part Status: Active
Number of Characters: 1
Size / Dimension: 0.500" H x 0.300" W x 0.240" D (12.70mm x 7.62mm x 6.09mm)
Digit/Alpha Size: 0.30" (7.62mm)
Display Type: 7-Segment
Common Pin: Common Anode
Color: Red
Voltage - Forward (Vf) (Typ): 1.7V
Current - Test: 5mA
Millicandela Rating: 3.6mcd
Wavelength - Peak: 645nm
Power Dissipation (Max): 37mW
Package / Case: 10-DIP (0.200", 5.08mm)
detail: Display Modules - LED Character and Numeric Red 7-Segment 1 Character Common Anode 1.7V 5mA 0.500" H x 0.300" W x 0.240" D (12.70mm x 7.62mm x 6.09mm) 10-DIP (0.200", 5.08mm)
