- دیتاشیت LP38692MP-ADJ/NOPB
LP38692MP-ADJ/NOPB دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | LP38692MP-ADJ/NOPB |
|---|---|
| حجم فایل | 92.022 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 27 |
دانلود دیتاشیت LP38692MP-ADJ/NOPB |
دانلود دیتاشیت |
|---|
سایر مستندات
LP38690-ADJ/LP38692-ADJ 27 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments LP38692MP-ADJ/NOPB
- Output Type: Adjustable
- Output Current: 1A
- Output Voltage: 1.25V~9V
- Dropout Voltage: -
- Output Polarity: Positive
- Number of Outputs: 1
- Maximum Input Voltage: 10V
- Operating Temperature: -40°C~+125°C
- Quiescent Current (Ground Current): 55uA
- Power Supply Rejection Ratio (PSRR): 55dB@(120Hz)
- Package: SOT-223-5
- Manufacturer: Texas Instruments
- Series: -
- Control Features: -
- Voltage - Output (Max): 9V
- Current - Quiescent (Iq): 55µA
- Supplier Device Package: SOT-223-5
- Voltage Dropout (Max): -
- Number of Regulators: 1
- PSRR: 55dB (120Hz)
- Mounting Type: Surface Mount
- Voltage - Output (Min/Fixed): 1.25V
- Current - Output: 1A
- Voltage - Input (Max): 10V
- Current - Supply (Max): 100µA
- Protection Features: Over Temperature
- Packaging: Cut Tape (CT)
- Base Part Number: LP38692
- Package / Case: TO-261-5, TO-261AB
- Part Status: Active
- Output Configuration: Positive
- detail: Linear Voltage Regulator IC 1 Output 1A SOT-223-5
