دیتاشیت HCPL-3101

HCPL-3100/01

مشخصات دیتاشیت

نام دیتاشیت HCPL-3100/01
حجم فایل 433.971 کیلوبایت
نوع فایل pdf
تعداد صفحات 14

دانلود دیتاشیت HCPL-3100/01

HCPL-3100/01 Datasheet

مشخصات

  • Manufacturer: Broadcom Limited
  • Series: -
  • Packaging: Tube
  • Part Status: Obsolete
  • Technology: Optical Coupling
  • Number of Channels: 1
  • Voltage - Isolation: 5000Vrms
  • Common Mode Transient Immunity (Min): 15kV/µs
  • Propagation Delay tpLH / tpHL (Max): 500ns, 500ns
  • Pulse Width Distortion (Max): -
  • Rise / Fall Time (Typ): 200ns, 200ns
  • Current - Output High, Low: -
  • Current - Peak Output: 600mA
  • Voltage - Forward (Vf) (Typ): 1.6V
  • Current - DC Forward (If) (Max): 20mA
  • Voltage - Output Supply: 15V ~ 30V
  • Operating Temperature: -40°C ~ 85°C
  • Mounting Type: Through Hole
  • Package / Case: 8-DIP (0.300", 7.62mm)
  • Supplier Device Package: 8-DIP
  • Approval Agency: UR
  • detail: 600mA Gate Driver Optical Coupling 5000Vrms 1 Channel 8-DIP
