HSMC-S670 Datasheet

HSMx-S660/670/690 Series

Datasheet specifications

Datasheet's name HSMx-S660/670/690 Series
File size 207.458 KB
File type pdf
Number of pages 11

Download Datasheet HSMx-S660/670/690 Series

Download Datasheet

Other documentations

No other documentation was found!

Technical specifications

  • Manufacturer: Broadcom Limited
  • Series: SunPower
  • Packaging: Cut Tape (CT)
  • Part Status: Obsolete
  • Color: Red
  • Configuration: Standard
  • Lens Color: White
  • Lens Transparency: Diffused
  • Millicandela Rating: 50mcd
  • Lens Style: Rectangle with Flat Top
  • Lens Size: 1.30mm x 1.25mm
  • Voltage - Forward (Vf) (Typ): 1.9V
  • Current - Test: 20mA
  • Viewing Angle: 165°
  • Mounting Type: Surface Mount
  • Wavelength - Dominant: 626nm
  • Wavelength - Peak: 630nm
  • Features: -
  • Package / Case: 0805 (2012 Metric)
  • Size / Dimension: 2.00mm L x 1.25mm W
  • Height (Max): 0.80mm
  • detail: Red 626nm LED Indication - Discrete 1.9V 0805 (2012 Metric)
