HSMS-C660 Datasheet

HSMx-C660

Datasheet specifications

Datasheet's name HSMx-C660
File size 156.57 KB
File type pdf
Number of pages 8

Download Datasheet HSMx-C660

Download Datasheet

Other documentations

No other documentation was found!

Technical specifications

  • Manufacturer: Broadcom Limited
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Obsolete
  • Color: Red
  • Configuration: Standard
  • Lens Color: White
  • Lens Transparency: Diffused
  • Millicandela Rating: 5mcd
  • Lens Style: Rectangle with Domed Top
  • Lens Size: 2.00mm x 1.00mm
  • Voltage - Forward (Vf) (Typ): 1.9V
  • Current - Test: 20mA
  • Viewing Angle: 155°
  • Mounting Type: Surface Mount, Right Angle
  • Wavelength - Dominant: 626nm
  • Wavelength - Peak: 639nm
  • Features: -
  • Package / Case: 2-SMD, No Lead
  • Supplier Device Package: Chip LED
  • Size / Dimension: 3.00mm L x 2.00mm W
  • Height (Max): 1.00mm
  • Base Part Number: HSMS-C660
  • detail: Red 626nm LED Indication - Discrete 1.9V 2-SMD, No Lead
