SZSL05T1G دیتاشیت

SZSL05T1G

مشخصات دیتاشیت

نام دیتاشیت SZSL05T1G
حجم فایل 88.364 کیلوبایت
نوع فایل pdf
تعداد صفحات 6

دانلود دیتاشیت SZSL05T1G

دانلود دیتاشیت

سایر مستندات

SL05T1 Series 5 pages

مشخصات فنی

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/TVS
  • Datasheet: onsemi SZSL05T1G
  • Breakdown Voltage: 6V
  • Unidirectional Channels: 1
  • Maximum Clamping Voltage: 11V
  • Reverse Stand-Off Voltage (Vrwm): 5V
  • Peak Pulse Current (Ipp)@10/1000μs: 5A@8/20us
  • Peak Pulse Power Dissipation (Ppp)@10/1000μs: 300W
  • Package: SOT-23-3
  • Manufacturer: onsemi
  • Series: Automotive, AEC-Q101
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Type: Zener
  • Voltage - Reverse Standoff (Typ): 5V
  • Voltage - Breakdown (Min): 6V
  • Voltage - Clamping (Max) @ Ipp: 11V
  • Current - Peak Pulse (10/1000µs): 5A (8/20µs)
  • Power - Peak Pulse: 300W
  • Power Line Protection: No
  • Applications: Automotive
  • Capacitance @ Frequency: 3.5pF @ 1MHz
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Mounting Type: Surface Mount
  • Package / Case: TO-236-3, SC-59, SOT-23-3
  • Supplier Device Package: SOT-23-3 (TO-236)
  • Base Part Number: SL05
  • detail: 11V Clamp 5A (8/20µs) Ipp Tvs Diode Surface Mount SOT-23-3 (TO-236)
