دیتاشیت MM74HC126M
مشخصات دیتاشیت
| نام دیتاشیت | MM74HC126M |
|---|---|
| حجم فایل | 70.016 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 9 |
MM74HC126M |
دانلود دیتاشیت |
|---|
سایر مستندات
MM74HC125, MMC126 9 pages
مشخصات فنی
- RoHS: true
- Category: Logic ICs/Buffer/Driver/Transceiver
- Datasheet: onsemi MM74HC126M
- output type: Tri-State
- Logic Family: 74HC
- Sink Current: 7.8mA
- Source Current: 7.8mA
- Supply Voltage: 2V~6V
- Number of Elements: 4
- Operating Temperature: -40°C~+85°C
- Number of Bits per Element: 1
- Package: SOP-14
- Manufacturer: onsemi
- Series: 74HC
- Packaging: Tube
- Part Status: Active
- Logic Type: Buffer, Non-Inverting
- Input Type: -
- Current - Output High, Low: 7.8mA, 7.8mA
- Voltage - Supply: 2V ~ 6V
- Mounting Type: Surface Mount
- Package / Case: 14-SOIC (0.154", 3.90mm Width)
- Supplier Device Package: 14-SOIC
- Base Part Number: MM74H
- detail: Buffer, Non-Inverting 4 Element 1 Bit per Element 3-State Output 14-SOIC
